Gravity: I2C TO GPIO shield V2.0 [Discontinued]

Gravity: I2C TO GPIO shield V2.0 [Discontinued]

✅ Made In USA

✅ Quick Delivery

✅ Cruelty Free

 (88 Reviews)
$7.56
$7.56 $12.00
SAVE 37% Sold out

add_shopping_cart

-

Ordered

local_shipping

- - -

Order Ready

redeem

- - -

Delivered

Gravity: I2C TO GPIO shield V2.0 [Discontinued] by DFRobot - The Pi Hut

Gravity: I2C TO GPIO shield V2.0 [Discontinued]

$7.56
$7.56 $12.00
SAVE 37% Sold out

Having troubles with inadequate digital I/O when using arduino with robots or interactive media? This I2C to I/O module helps you solve the problem, Arduino has only two data lines (SCL-Analog PIN5, SDA-Analog PIN4) and I2C can transfer I / O module communication, to convert the 16 digital IO ports, read-write. 8 simultaneous parallel modules, each module can be set to address.​

Specification

  • Module power supply: +5 V
  • 16 Digital IO port comes with internal pull-up
  • Can be set to eight addresses (address range of 0x20 ~ 0x27)
  • 8 modules simultaneously in parallel (I2C bus need to pull together)
  • Module Size: 56x53mm (2.21x2.08 in)

Documents

  • Wiki (I2C to GPIO Shield V2.0)
  • Documents

Shipping List

  • I2C To GPIO shield V2.0 x1
