ATOMIC Display Base (GW1NR)

Description

Atomic Display Base is a high-definition monitor driver unit that uses an FPGA to simulate traditional SPI TFT-LCD data output, supporting a maximum 720P (1280 x 720) image output. It incorporates a dedicated RGB-to-HD multimedia signal conversion chip for wide compatibility in display output. Users can pair it with Atom series hosts to meet different memory and application requirements. The Atomic Display Base can replace the PC control scheme of traditional display panels, providing a more cost-effective solution. It is suitable for industrial control displays, smart home information screens, educational and conference presentations, and remote monitoring displays.

Features

• Equipped with FPGA (Gowin GW1NR-9C)
• Built-in LT8618SX RGB-to-HD multimedia signal conversion chip (supports 24-bit color depth)
• SPI interface (FPGA) + I2C interface (LT8618SX)
• Maximum 720P (1280x720) image output
• Multiple output modes, optimized frame rate up to 12 ~ 16FPS
• Development Platforms: Arduino, ESP32-IDF (UIFlow not supported yet)

Includes

• 1 x Atomic Display Base

Applications

• Monitor input signal source
• High-definition data dashboard
