Adafruit PiTFT 2.2" HAT Mini Kit - 320 x 240 2.2" TFT - No Touch

The cute PiTFT got even more adorable with this little primary display for Raspberry Pi in HAT form! It features a 2.2" display with 320 x 240 16-bit colour pixels. The HAT uses the high-speed SPI interface on the Pi and can use the mini display as a console, X window port, displaying images or video etc. Best of all, it plugs right in on top of your Model A+ or B+ and fits into our case quite nicely.

It's designed to plug directly into the Raspberry Pi 2, Pi 3, Pi 4, Pi 5, Pi Zero, or Raspberry Pi 1 Model A+ or B+. While not specifically designed for Pi Model A or B, you can use it with A/B if you solder in an extra-tall 2x13 header (not included) instead of the included 2 x 20 header

This design uses the hardware SPI pins (SCK, MOSI, MISO, CE0, CE1) as well as GPIO #25. All other GPIO are unused and are available on a 25-pin long breakout line. Since we had a tiny bit of space, there are 4 flat tactile switches wired to four GPIOs, that you can use if you want to make a basic user interface. For example, you can use one as a power on/off button.

Comes as a fully assembled display PCB and an additional 2 x 20 GPIO header. Some light soldering is required to attach the 2x20 GPIO header to the HAT, but it's fast and easy for anyone with a soldering iron and solder. You can also swap the plain female header we have with a 'stacky' type that lets you plug in a hat or GPIO cable on top or a slim ultra-low-profile header.

To make it super easy to use: we've created a custom kernel package based on Notro's awesome framebuffer work, so you can install it over your existing Raspbian (or derivative) images in just a few commands. Our tutorial series shows you how to install the software, play small videos, or display images such as from your PiCam and more!

Revision History:

As of July 10, 2024 – we've updated this PCB with Adafruit Pinguin to make a lovely and legible silkscreen - you may get the new PCB or the older version with vector fonts - both are identical other than the fancy silkscreen.

Specifications

• Dimensions: 65mm x 57mm x 6mm
• Screen Dimensions: 55mm x 40mm

Resources

• Product Tutorial
